Quadro Series | Square Head Dough Divider

Erika Record | Quadro Series | Square Head

The Quadro Series is available across our entire lineup

Partner: Erika
Category: Divider/Rounders
Industry: Bakeries / Food Service
Production: Retail & Wholesale

The Quadro Series of Erika Divider/Rounders is the perfect solution for bakers who offer round, square or rectangular products including ciabatta, demi-baguettes, and focaccia breads.

The Quadro Series is available across our entire lineup including Semi RH, Easy, Easy Plus, Full, and Full Classic. The 9 Q3 (9 Part), 30 Q2 (30 part), and 36 Q3 (36 part) variations offer even greater versatility by also being able to round dough like our traditional offerings.

We also have 10 (10 Q2), 12 (12 Q3), 15 (15 Q2), and 18 (18 Q3) part variations that are capable of making larger rectangular pieces.

For added versatility, models with a Q2 designation are interchangeable amongst other Q2 models. Likewise, models with a Q3 designation are interchangeable amongst other Q3 models.


MODEL	NET WEIGHT	DIMENSIONS (D X W X H)	SHIPPING WEIGHT	SHIPPING DIMENSIONS (D X W X H)
SEMI Fixed & Interchangeable (Removable Head Series)	770 lbs (350 kg)	28.5" x 25.5" x 78.75" (724mm x 648mm x 2000mm)	880 lbs (399 kg)	31" x 33" x 63" (788mm x 839mm x 1601mm)
EASY Fixed & Interchangeable (Removable Head Series)	816 lbs (370 kg)	31" x 26.75" x 60" (788mm x 680mm x 1524mm)	946 lbs (429 kg)	35" x 35" x 76" (889mm x 889mm x 1930mm)
EASY PLUS Fixed & Interchangeable (Removable Head Series)	816 lbs (370 kg)	31" x 26.75" x 60" (788mm x 680mm x 1524mm)	946 lbs (429 kg)	35" x 35" x 76" (889mm x 889mm x 1930mm)
FULL Fixed, Non-Interchangeable Series	1100 lbs (499 kg)	29.5" x 32" x 61" (750mm x 813mm x 1550mm)	1540 lbs (699 kg)	35" x 35" x 76" (889mm x 889mm x 1930mm)
FULL CLASSIC Fixed, Non-Interchangeable Series	1100 lbs (499 kg)	27" x 33.5" x 64" (686mm x 851mm x 1626mm)	1540 lbs (699 kg)	35" x 35" x 76" (889mm x 889mm x 1930mm)

MODEL

NET
WEIGHT

DIMENSIONS
(D X W X H)

SHIPPING
WEIGHT

SHIPPING DIMENSIONS
(D X W X H)

SEMI
Fixed & Interchangeable
(Removable Head Series)

770 lbs
(350 kg)

28.5" x 25.5" x 78.75"
(724mm x 648mm x 2000mm)

880 lbs
(399 kg)

31" x 33" x 63"
(788mm x 839mm x 1601mm)

EASY
Fixed & Interchangeable
(Removable Head Series)

816 lbs
(370 kg)

31" x 26.75" x 60"
(788mm x 680mm x 1524mm)

946 lbs
(429 kg)

35" x 35" x 76"
(889mm x 889mm x 1930mm)

EASY PLUS
Fixed & Interchangeable
(Removable Head Series)

816 lbs
(370 kg)

31" x 26.75" x 60"
(788mm x 680mm x 1524mm)

946 lbs
(429 kg)

35" x 35" x 76"
(889mm x 889mm x 1930mm)

FULL
Fixed, Non-Interchangeable Series

1100 lbs
(499 kg)

29.5" x 32" x 61"
(750mm x 813mm x 1550mm)

1540 lbs
(699 kg)

35" x 35" x 76"
(889mm x 889mm x 1930mm)

FULL CLASSIC
Fixed, Non-Interchangeable Series

1100 lbs
(499 kg)

27" x 33.5" x 64"
(686mm x 851mm x 1626mm)

1540 lbs
(699 kg)

35" x 35" x 76"
(889mm x 889mm x 1930mm)


MODEL & ROUNDING PLATE	# OF PARTS	PRODUCT DIMENSIONS	DOUGH PIECES WEIGHT
10 Q2*	10	2 3/8 x 7 1/8 in \| 60 x 181 mm	4 1/8 - 15 oz \| 117 - 425g
15 Q2*	15	2 3/8 x 4 3/8 in \| 60 x 111 mm	2 3/4 - 10 oz \| 78 - 284g
30 Q2ᵗ*	30	2 3/8 x 2 3/8 in \| 60 x 60 mm	1 3/8 - 5 oz \| 39 - 142g
9 Q3ᵗ**	9	2 1/4 x 2 1/4 in \| 57 x 57 mm	4 - 18 oz \| 113 - 510g
12 Q3**	12	2 1/4 x 6 3/4 in \| 60 x 171 mm	3 -13 1/2 oz \| 85 - 383g
18 Q3**	18	2 1/4 x 4 1/2 in \| 57 x 114 mm	2 - 9 oz \| 57 - 256g
36 Q3ᵗ**	36	2 1/4 x 2 1/4 in \| 57 x 57 mm	1 - 4 1/2 oz \| 29 - 128g
Q2 models feature interchangeable knife head assemblies that are compatible with other Q2 assemblies *Q3 models feature interchangeable knife head assemblies that are compatible with other Q3 assemblies			ᵗ indicates both dividing and rounding capabilities

MODEL & ROUNDING PLATE

# OF PARTS

PRODUCT DIMENSIONS

DOUGH PIECES WEIGHT

10 Q2*

2 3/8 x 7 1/8 in | 60 x 181 mm

4 1/8 - 15 oz | 117 - 425g

15 Q2*

2 3/8 x 4 3/8 in | 60 x 111 mm

2 3/4 - 10 oz | 78 - 284g

30 Q2ᵗ*

2 3/8 x 2 3/8 in | 60 x 60 mm

1 3/8 - 5 oz | 39 - 142g

9 Q3ᵗ**

2 1/4 x 2 1/4 in | 57 x 57 mm

4 - 18 oz | 113 - 510g

12 Q3**

2 1/4 x 6 3/4 in | 60 x 171 mm

3 -13 1/2 oz | 85 - 383g

18 Q3**

2 1/4 x 4 1/2 in | 57 x 114 mm

2 - 9 oz | 57 - 256g

36 Q3ᵗ**

2 1/4 x 2 1/4 in | 57 x 57 mm

1 - 4 1/2 oz | 29 - 128g

*Q2 models feature interchangeable knife head assemblies that are compatible with other Q2 assemblies
**Q3 models feature interchangeable knife head assemblies that are compatible with other Q3 assemblies

ᵗ indicates both dividing and rounding capabilities

Erika Record | Quadro Series | Square Head Make Round, Square & Rectangular Products
